3266A-W Trimmer
Category： 3266A-W
Product Detail
| Cermet Trimmer 3266A-W | ||
| Electrical Characteristics | Standard Resistance Range | 10Ω~5MΩ |
| Resistance Tolerance | ±10% ±5% (customization) | |
| Terminal Resistance | ≤2%R or 2Ω | |
| Insulation Resistance | R1≥ 1GΩ（500V） | |
| Rated Power | 0.25W ( 200V max) | |
| Withstand Voltage | 600Vac | |
| Contact Resistance Variation (CRV) | ≤3%R or 3Ω | |
| Effective Electrical Travel | 12±1 cycles | |
| Environment Characteristics | Temperature Range | -55°C+125°C |
| Temperature Coefficient | ±250, ±100ppm/°C | |
| Collision | ΔR≤±3%R or 3Ω, ΔUab/Uac≤±5%R | |
| Vibration | ΔR≤±3%R or 3Ω, ΔUab/Uac≤±5%R | |
| Moisture Proof | ΔR≤±2%R,CRV≤±3%R or 3Ω | |
| Electrical Endurance (70°C,0.25W,1000h) | ΔR≤±5%R,CRV≤±5%R or 5Ω | |
| Mechanical Endurance (200 cycles) | CRV≤±3%R or 3Ω, R1≥ 1GΩ | |
| Storage at High Temperature (125°C,250h) | ΔUab/Uac≤±2%R,CRV≤±3%R or 3Ω | |
| Operation at Low Temperature (-55°C,0.25W) | ΔUab/Uac≤±2%R,CRV≤±3%R or 3Ω | |
| Physical Characteristics | Total Mechanical Travel | 12±1 cycles |
| Starting Torque | ≤21mN.m | |
| Clutch Torque | ≤21mN.m | |
Keyword：3266A-W Trimmer
Prev： Nothing！
Next： Nothing！
3266A-W Trimmer
Cermet Trimmer 3266A-W Electrical Characteristics Standard Resistance Range 10Ω~5MΩ Resistance Tolerance ±10% ±5% (customization) Terminal Resistance ≤2%R or 2Ω Insulation Resistance R1≥ 1GΩ(500V) Rated Power 0.25W ( 200V max) Withstand Voltage 600Vac Contact Resistance Variation (CRV) ≤3%R or 3Ω Effective Electrical Travel 12±1 cycles Environment Characteristics Temperature Range -55°C+125°C Temperature Coefficient ±250, ±100ppm/°C Collision ΔR≤±3%R or 3Ω, ... FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
