RV30 Rotary Pot
Category： RV30
Product Detail
| Carbon Potentiometer RV30 | ||
| Electrical Characteristics | Total Resistance | 50Ω-2MΩ |
| Total Resistance Tolerance | ±10% | |
| Max. Operation Voltage | 315VAC | |
| Rated Power | 0.25W | |
| Slider Noise | ≤3%R or 3Ω | |
| Insulation Resistance | ≥100MΩ at DC1000 | |
| Mechanical Characteristics | Total Rotational Angle | 280°±10° |
| Rotational Torque | 51-306gf.cm | |
| Rotational Life | 15,000 cycles | |
| Machanical Rotational Angle | 300°±5° | |
| Temperature Range | -10℃-85℃ | |
Keyword：RV30 Rotary Pot
Prev： Nothing！
Next： Nothing！
RV30 Rotary Pot
Carbon Potentiometer RV30 Electrical Characteristics Total Resistance 50Ω-2MΩ Total Resistance Tolerance ±10% Max. Operation Voltage 315VAC Rated Power 0.25W Slider Noise ≤3%R or 3Ω Insulation Resistance ≥100MΩ at DC1000 Mechanical Characteristics Total Rotational Angle 280°±10° Rotational Torque 51-306gf.cm Rotational Life 15,000 cycles Machanical Rotational Angle 300°±5° Temperature Range -10℃-85℃ FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
