3540 2W Potentiometer/3540 potentiometer
Category： 3540
Product Detail
| Wire-wound Potentiometer WXD3540 | ||
| Electrical Characteristics | Standard Resistance Range | 100Ω~100KΩ |
| Resistance Tolerance | ±5% | |
| Independent Linearity | ±0.25% | |
| Terminal Resistance | ≤2%R or 5Ω | |
| Contact Resistance Variation (CRV) | ≤3%R or 3Ω | |
| Insulation Resistance | R1≥ 1GΩ | |
| Withstand Voltage | 101.3kPa 710V 8.5kPa 470V | |
| Rated Power | 2W ( 500V max) | |
| Effective Electrical Travel | ≥3600° -10° | |
| Environment Characteristics | Temperature Range | -55°C~+125°C |
| Temperature Coefficient | ±100ppm/°C | |
| Temperature Variation | ΔR≤±2%R,ΔUab/Uac≤±1%R | |
| Collision (390m/S^2, 4000 times) | ΔR≤±1%R | |
| Vibration (10-500HZ, 0.75mm or 98m/S^2 6h) | ΔR≤±1%R, ΔUab/Uac≤±2%R | |
| Climate Category | ΔR≤± 3%R, R1≥100MΩ | |
| Electrical Endurance (70°C,2W,1000h) | ΔR≤± 3%R | |
| Mechanical Endurance (10000 cycles) | ΔR≤± 3%R | |
| Steady Damp-Heat | ΔR≤± 3%R, R1≥100MΩ | |
| Physical Characteristics | Total Mechanical Travel | 3600°±10° |
| Starting Torque | ≤36mN.m | |
| Clutch Torque | ≤300mN.m | |
Keyword：3540 2W Potentiometer/3540 potentiometer
Prev： Nothing！
Next： Nothing！
3540 2W Potentiometer/3540 potentiometer
Wire-wound Potentiometer WXD3540 Electrical Characteristics Standard Resistance Range 100Ω~100KΩ Resistance Tolerance ±5% Independent Linearity ±0.25% Terminal Resistance ≤2%R or 5Ω Contact Resistance Variation (CRV) ≤3%R or 3Ω Insulation Resistance R1≥ 1GΩ Withstand Voltage 101.3kPa 710V 8.5kPa 470V Rated Power 2W ( 500V max) Effective Electrical Travel ≥3600° -10° Environment Characteristics Temperature Range... FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
