WX118 50mm Long Shaft Potentiometer/wx118 potentiometer
Category： WX118
Product Detail
| Long Shaft Potentiometer WX118 | ||
| Electrical Characteristics | Range of nominal resistance | 5Ω~22KΩ |
| Resistance tolerance | ±5% | |
| Terminal resistance | ≤±0.2%R or 5Ω | |
| Peak Noise | ≤100Ω | |
| Insulation resistance | ≥ 200MΩ (100V AC) | |
| Withstand voltage | 500V (DC or AC peak value) | |
| Electrical angle | 258° ± 5 ° | |
| Rated power | 1W ( 300V 70 °C ) | |
| Environment Characteristics | Temperature range | -55°C~+125°C |
| TCR | ±100×10-6/°C | |
| Collision (390m/S2, 4000 times) | ΔR≤±1%R | |
| Vibration (10-500HZ, 0.75mm, 6h) | ΔR≤±1%R, ΔUab/Uac≤±2%R, Electrical break≤100μS | |
| Temperature variation (-55°C/30min, +125°C/30min, 5 cycles) | ΔR≤±2%R, ΔUab/Uac≤±2%R | |
| Climate category (IEC68-2-2) | ΔR≤± (5%R+0.1Ω),Insulation Resistance≥100MΩ | |
| Electrical endurance (2W, 1000h) | ΔR≤± 3%R | |
| Mechanical endurance (1000 cycles) | ΔR≤± (10%R+0.5Ω), CRV≤±3%R or 5Ω | |
| Steady damp heat (IEC68-2-3, Ca, 96h) | ΔR≤± 3%R, Insulation Resistance≥100MΩ,starting torque ≤20mN.m | |
| Physical Characteristics | Total mechanical travel | 300° ± 5 ° |
| Rotational torque | 2-10mN.m | |
| Standard package | 25 pcs /box | |
Keyword：WX118 50mm Long Shaft Potentiometer/wx118 potentiometer
Prev： Nothing！
Next： Nothing！
WX118 50mm Long Shaft Potentiometer/wx118 potentiometer
Long Shaft Potentiometer WX118 Electrical Characteristics Range of nominal resistance 5Ω~22KΩ Resistance tolerance ±5% Terminal resistance ≤±0.2%R or 5Ω Peak Noise ≤100Ω Insulation resistance ≥ 200MΩ (100V AC) Withstand voltage 500V (DC or AC peak value) Electrical angle 258° ± 5 ° Rated power 1W ( 300V 70 °C ) Environment Characteristics Temperature range -55°C~+125°C TCR ±100×10-6/°C Collision (390m/S2, 4000 times) ΔR≤±1%R Vibration (10-500HZ, 0.75mm... FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
