WXD3-13 2W Potentiometer/wire wound potentiometer
Category： WXD3-13
Product Detail
| Wire-wound Potentiometer WXD3-13 | ||
| Electrical Characteristics | Standard Resistance Range | 100Ω~47KΩ |
| Resistance Tolerance | ±5% | |
| Independent Linearity | ±0.3% | |
| Rated Power | 2W ( 85°C) | |
| Voltage Rating | 160V | |
| Mechanical Characteristics | Total Mechanical Travel | 3600°±10° |
| Starting Torque | 3.5-100mN.m | |
Keyword：WXD3-13 2W Potentiometer/wire wound potentiometer
Prev： Nothing！
Next： Nothing！
WXD3-13 2W Potentiometer/wire wound potentiometer
Wire-wound Potentiometer WXD3-13 Electrical Characteristics Standard Resistance Range 100Ω~47KΩ Resistance Tolerance ±5% Independent Linearity ±0.3% Rated Power 2W ( 85°C) Voltage Rating 160V Mechanical Characteristics Total Mechanical Travel 3600°±10° Starting Torque 3.5-100mN.m FOB Price: US $0.01 - 99/ Piece Min.Order Quantity: 1000 Pieces for Trimming Pot; 100 Pieces for Wire-wound Pot; and etc. Supply Ability: 100000000 Pieces per Month Production Time: 5-10 workdays for regular orders; 1-5 workdays for samples order. Port: Shenzhen, Shanghai, Ningbo, Guangzhou, Chengdu and etc Payment Terms: Western Union, Visa/Master Card, T/T, Paypal, e-checking and etc Services: ODM, OEM
